WORKSHOP EQUIPMENT - LIFTING EQUIPMENT
LIFTING EQUIPMENT
LIFTING POINTS WITH RFID
SW
S
LIFTING POINT 8211 / 8212

SW
A • Rotates through 360º and pivots 90º
S 90° pivot • Manufactured from alloy steel, quenched
G and tempered
B • Tested in accordance with EN1677-1
D A • Certified by DGUV GS-OA 15-04
• Load rated parts are 100% magnaflux
cracked detected
G • Individual forged parts and cap screw are
B traceable to Test Certification
F D • Bolt threads are metric
• Proof tested to 2�5 times the WLL (Working
Load Limit)
C • Fatigue rated to 20,000 cycles at 1�5 times
H
F the WLL
• All YOKE Lifting points meet or exceed all
E 360°rotation the requirements of ASME B30�26
RFID • Quick and simple assembly, just a tapped
C
H equipped hole is required
M
E

M

WORKING M
Metric LOAD THREAD A B C D E F G H S SW TORQUE N.W
IN
REF LIMIT Nn kg
(tonnes) mm MM
8211003 0�3 M8x1�25 30 35 35 10 11 85 55 29 6 13 30 0�2
8211006 0�63 M10x1�5 30 35 36 10 16 85 55 29 6 17 60 0�3
8211010 1 M12x1�75 33 37 44 14 18 98 57 36 8 19 100 0�5
8211012 1�2 M14x2 33 37 45 14 21 98 57 36 10 22 120 0�5
8211015 1�5 M16x2 33 37 46 14 24 98 57 36 10 24 150 0�5
8211020 2 M18x2�5 50 54 57 17 26 140 82 44 12 30 200 1�3
8211025 2�5 M20x2�5 50 54 57 17 30 140 82 44 12 30 250 1�3
8211040 4 M24x3 50 54 59 17 36 140 82 44 14 36 400 1�4
8211042 4 M27x3 60 65 79 23 38 170 99 62 17 41 400 2�8
8211050 5 M30x3�5 60 65 81 23 48 170 99 62 17 46 500 3�1
8211070 7 M36x4 60 65 88 23 54 178 99 65 22 55 700 3�3
8211080 8 M36x4 77 85 101 27 62 225 124 78 22 55 800 5�8
8211100 10 M42x4�5 77 85 104 27 72 225 124 78 24 65 1000 6�3
8211150 15 M42x4�5 95 104 112 36 63 256 158 86 24 65 1500 10�8
8211200 20 M48x5 95 104 120 36 72 259 158 90 27 75 2000 11�6

WORKING M TORQUE
UNC Thread LOAD THREAD A B C D E F G H S SW IN N.W
REF LIMIT lbs
(tonnes) INCH INCH Nn
8212010 1 1/2-13UNC 1�30 1�46 1�73 0�53 0�75 3�86 2�24 1�42 5/16 3/4 100 1�1
8212015 1�5 5/8-11UNC 1�30 1�46 1�81 0�53 0�94 3�86 2�24 1�42 3/8 1 5/16 150 1�1
8212020 2�5 3/4-10UNC 1�97 2�13 2�20 0�65 1�10 5�51 3�23 1�73 1/2 1 1/8 250 2�9
8212025 2�5 7/8-9UNC 1�97 2�13 2�28 0�65 1�10 5�51 3�23 1�73 5/8 1 5/16 300 2�9
8212040 4 1-8UNC 1�97 2�13 2�34 0�65 1�61 5�51 3�23 1�73 5/8 1 1/2 400 3�1
8212050 5 1 1/4-7UNC 2�36 2�56 3�23 0�89 1�61 6�69 3�90 2�44 7/8 1 7/8 500 6�8
8212080 8 1 1/2-6UNC 3�03 3�35 4�01 1�04 2�25 8�86 4�88 3�07 1 2 1/4 800 12�8
8212150 15 1 3/4-5UNC 3�74 4�09 4�48 1�42 2�63 10�08 6�22 3�39 1 2 5/8 1500 24�0
CAD reference point
8212200 20 2-4�5UNC 3�74 4�09 4�76 1�42 3 10�20 6�22 3�54 1 1/4 3 2000 25�5
