WORKSHOP EQUIPMENT - LIFTING EQUIPMENT
LIFTING EQUIPMENT
SW LIFTING POINTS WITH RFID
S
ANCHOR POINT 8231 / 8232

D 180° pivot • Rotates through 360º and pivots 90º
R • Manufactured from alloy steel, quenched
and tempered
SW • Tested in accordance with EN1677-1
B S • Certified by DGUV GS-OA 15-04
F • Load rated parts are 100% magnaflux
cracked detected
• Individual forged parts and cap screw are
C
H traceable to Test Certification
• Bolt threads are metric
E D • Proof tested to 2�5 times the WLL (Working
Load Limit)
R • Fatigue rated to 20,000 cycles at 1�5 times
M
A the WLL
G B 360°rotation • All YOKE Lifting points meet or exceed all
the requirements of ASME B30�26
RFID
F equipped • Quick and simple assembly, just a tapped
hole is required
C
H

WORKING M
Metric LOAD E A B C D E F G H S SW TORQUE N.W
IN
REF LIMIT THREAD Nn kg
(tonnes) mm M MM
8231005 0�5 M8x1�25 A 33 42 28 11 12 80 58 23 6 13 30 0�3
G
8231007 0�7 M10x1�5 33 41 29 11 15 80 58 23 6 17 60 0�3
8231010 1�0 M12x1�75 33 40 31 11 20 80 58 23 8 19 100 0�3
8231015 1�5 M14x2 50 56 45 17 21 117 90 36 10 22 120 0�9
8231020 2�0 M16x2 50 54 46 17 24 117 90 36 10 24 150 0�9
8231025 2�5 M18x2�5 65 78 57 20 26 153 108 44 12 30 200 1�9
8231030 3�0 M20x2�5 50 52 49 17 30 117 90 36 12 30 250 1�0
8231050 5�0 M24x3 72 81 59 25 36 163 125 44 14 36 400 2�6
8231056 5�6 M27x3 87 86 79 30 38 204 148 62 17 41 400 4�9
8231078 7�8 M30x3�5 87 94 81 30 48 204 148 62 17 46 500 5�0
8231125 12�5 M36x4 110 112 98 36 54 247 188 75 22 55 1000 9�6
8231156 15�6 M42x4�5 110 101 108 36 63 247 188 83 24 65 1500 10�9
8231200 20�0 M48x5 110 97 113 36 72 248 188 83 27 75 2000 11�6
8231220 22�0 M56x5�5 123 116 121 36 84 274 202 91 27 85 2100 15�0
8231225 22�5 M64x6 123 111 126 36 100 274 202 91 32 95 2200 16�3

WORKING M
UNC Thread LOAD THREAD A B C D E F G H R S SW TORQUE N.W
IN
REF LIMIT Nn lbs
(tonnes) INCH INCH
8232010 0�8 1/2-13UNC 1�30 1�57 1�20 0�41 0�81 3�17 2�28 0�90 0�67 5/16 3/4 100 1�8
8232020 1�6 5/8-11UNC 1�97 2�13 1�81 0�65 1�13 4�61 3�54 1�42 1�06 3/8 15/16 150 2�0
8232030 2�4 3/4-10UNC 1�97 2�07 1�89 0�65 1�54 4�61 3�54 1�42 1�06 1/2 1 1/8 250 2�2
8232038 3�0 7/8-9UNC 2�56 2�99 2�28 0�79 1�42 6�02 4�25 1�73 1�34 5/8 15/16 300 4�3
8232050 4�5 1-8UNC 2�81 3�17 2�34 0�98 1�61 6�38 4�92 1�73 1�46 5/8 1 1/2 400 5�7
8232078 6�25 1 1/4-7UNC 3�43 3�66 2�23 1�18 2�09 8�07 5�83 2�44 1�79 7/8 1 7/8 500 11�0
8232125 10�0 1 1/2-6UNC 4�29 4�38 3�87 1�42 2�40 9�92 7�40 3�07 2�22 1 2 1/4 800 21�2
8232200 16 2-4�5UNC 4�61 3�80 4�46 1�42 3 9�93 7�71 3�35 2�38 1 1/4 3 2000 25�6
CAD reference point
