WORKSHOP EQUIPMENT - SURFACE FINISHING EQUIPMENT
DIPROMINI
FLEXIBLE-SHAFT DRIVE - SLIP JOINT CONNECTION FMR/D...

Dipromini polishing/filing Machine with connection for Diprofil micro
motor type HPM-B1 which should be connected to, and controlled by, the
DIPROFIL DPU-3, TPU-20 or corresponding power units� Available with
three different stroke lengths: 0,5 mm (FMR/D5), 1,0 mm (FMR/D10) or 1,5
mm (FMR/D15)�
Technical data
Tool holder: max Ø 3,6 mm
Stroke length: 0,5, 1,0 or 1,5 mm
Speed: max 12�000 rpm recommended: 5�000 - 11�000 rpm
Dimension: Ø 24 mm
Weight: approx� 120 g
Noise: < 70 dB(A) at 9�000 rpm
Vibrations: stroke 0,5 mm: <2,5 m/s², stroke 1,0 mm: 1,5 - 3 m/s², stroke 1,5
mm: 1,5 - 4 m/s²
Frequency weighed hand/arm vibration, principally in accordance with ISO
28927-8�
For further details, see diagram and other information in the corresponding
Operation Guide�

REF Stroke length
FMR/D5 0,5 mm
FMR/D10 1,0 mm
FMR/D15 1,5 mm

SPARE PARTS FMR/S...

17 10 6 5 11 15 14
3
13 18

4 1
2
9
8 7 12
Lubrication 16

Pos. Pcs. REF Description Pos. Pcs. REF Description
1 1 DIPFMR1 Housing 9 1 DIPFMR7 Bearing washer
2 1 DIPFMR73 Guide steering (front-piece) 10 1 DIP42039 Screw
3 1 DIPFMR74 Guide steering (back-piece) FMR-2/P 11 1 DIP44022 Ball bearing
4 1 DIPFMR3 Tool-holder 12 1 DIPFMR54 Nut for main spindle
5 1 DIPFMR9 Washer 13 1 DIPFMR1 Spindle drive mounting
1 DIPFMR45 Main spindle 45* 14 1 DIP43016 Back piece
Pin
CAD reference point 7 1 2 DIPFMR50 Main spindle 50* 16 1 DIPFMR1 Connetcing Sleeve
1
15
1
DIPFMR5
6
DIPFMR46
Main spindle 46*
Spindel end cover
1
Locking Screw
Ball bearing
DIP42038
17
DIP44024
Spacer
DIPFMR1
18
DIPFMR8
1
8
1
*DIPFMR45 for Mini polishing/filing machine FMR/S5 (stroke length 0,5 mm)�
*DIPFMR46 for Mini polishing/filing machine FMR/S15 (stroke length 1,0 mm)�
*DIPFMR50 for Mini polishing/filing machine FMR/S10 (stroke length 1,5 mm)�
