WORKSHOP EQUIPMENT - MOULD MAINTENANCE EQUIPMENT
MOULD MAINTENANCE EQUIPMENT

DME SMART SERIES M2+ M2+
®

ADVANCED HOT RUNNER TEMPERATURE CONTROL AND PROCESS
MONITORING WITH WORLD CLASS FEATURES
A fully featured controller platform with advanced capabilities for superior
moulding performance� Well suited for tight process control on all co-
injection applications, it is your best choice as a direct replacement for many
existing outdated controller platforms�
Unlock your operations full potential�

Key features

LARGE INTUITIVE TOUCH SCREEN CONTROLS
• Modernized interface
• Quick and easy to use
• Rapid response rates
• Familiar gestures like pinch-to-zoom
• Available in 8”, 12” and 17” formats

ADVANCED FUNCTIONALITY
• KORTEC auto cavity balancing
• Auto leak detection
• Auto tool diagnostics
• TC auto slave
• And much more

IO ALARM INTERLOCK
• Interface with any injection machine
• Triggers an alarm when issues are identified
• Pauses the moulding process until corrected
• Helps maintain process consistency

WIRELESS NETWORK CONTROL (WLAN)
• Multi cell operation
• Multiple IP operation
• Download/Upload tool set-up
• Valuable for clean room applications

Cabinet # of Cards # of Zones Dimensions WxDxH
Size (Max) (Max) cm (in.)
XS 6 24 31x45x81 (12x18x32)
S 12 48 36x45x96 (14x18x38)
M 24 96 45x60x116 (18x24x46)
L 36 144 45x60x141 (18x24x56) CAD reference point
XL 63 252 56x61x168 (22x24x66)
Based on 4z-15A cards� Increase max zones with 6z-5A cards�
Includes
• 4�8 m (15’) cable set�
• Quick start guide�
