Page 202 - DME Workshop Equipment Catalogue 2023 EN

A
SURF
WORKSHOP EQUIPMENT - SURFACE FINISHING EQUIPMENT
CE FINISHING EQUIPMENT
GRINDING PINS
POLISHING/GRINDING PINS (BROWN) PK 1350 ...

Features:
• Soft rubber bond - soft grinding, high surface finish quality, low chip
production
• Vmax: 15�000 min -1

REF Head Ø Head length Shank Ø Total length Grain Shape
PK13500408 4 8 3 38 220 20
PK13500510 5 10 3 40 220 20
PK13500610 6 10 3 40 220 20
PK13500810 8 10 3 40 220 20
PK13500816 10 10 3 40 220 20
PK13501313 13 13 3 43 220 20
PK13501616 16 16 3 46 220 20
PK13500816 8 16 6 56 220 20
PK13501020 10 20 6 60 220 20
PK13501320 13 20 6 60 220 20
PK13501620 16 20 6 60 220 20
PK13501632 16 32 6 72 220 20
PK13502020 20 20 6 60 220 20
PK13502032 20 32 6 72 220 20
PK13503210 32 10 6 50 220 20
PK13502032 20 32 6 60 220 20

PK135016 Ø 16 - 6 55 220 20

POLISHING/GRINDING PINS (GREEN) PK 1360 ...

Features:
• Soft rubber bond - soft grinding, high surface finish quality, low chip
production
• Vmax 15�000 min -1

REF Head Ø Head length Shank Ø Total length Grain Shape
PK13600408 4 8 3 38 280 20
PK13600510 5 10 3 40 280 20
PK13600610 6 10 3 40 280 20
PK13600810 8 10 3 40 280 20
PK13601010 10 10 3 40 280 20
PK13601313 13 13 3 43 280 20
PK13601616 16 16 3 46 280 20
PK13600816 8 16 6 56 280 20
PK13601020 10 20 6 60 280 20
PK13601320 13 20 6 60 280 20
PK13601620 16 20 6 60 280 20
PK13602020 20 20 6 60 280 20
PK13602032 20 32 6 72 280 20
PK13603232 32 32 6 72 280 20
PK13603210 32 10 6 50 280 20
PK13604010 40 10 6 50 280 20
PK13603216 32 16 6 56 280 20 CAD reference point
PK13603220 32 20 6 60 280 20
PK13604020 40 20 6 60 280 20

200 store.dme.net
