WORKSHOP EQUIPMENT - SURFACE FINISHING EQUIPMENT
CE FINISHING EQUIPMENT
PRECISION CBN TOOLS
ORIGINAL DIPROFIL PRECISION CBN TOOLS Info

Diprofil CBN Rotary Tools are made from carefully selected CBN (Cubic
Boron Nitride), precisely bonded to obtain the best physical properties for
added strength and resistance to wear� CBN tools are excellent for use on
Tool Steels, Stainless Steels and Cast Iron�

Other shapes, dimensions and grit sizes available upon request�

ORIGINAL DIPROFIL PRECISION CBN TOOLS B ...

Shape Dimensions Grit Size REF Shank diameter
D 0,8, T 4,0, B 7, L 46 B 107 B0308LH3 Ø 3,0 mm
D 1,0, T 4,0, B 8, L 46 B 107 B0310LH3
D 1,5, T 4,0, B 10, L 46 B 107 B0315LH3
Cylinder
D 2,0, T 5,0, B 14, L 46 B 151 B0320LH3
D 2,5, T 5,0, B 19, L 46 B 151 B0325LH3
D 3,0, T 5,0, B 19, L 46 B 151 B0330LH3
D 3,5, T 5,0, L 44 B 151 B0335LH3
D 4,0, T 5,0, L 44 B 151 B0340LH3
D 4,5, T 5,0, L 44 B 151 B0345LH3
Cylinder
D 5,0, T 6,0, L 45 B 151 B0350LH3
D 5,5, T 6,0, L 45 B 151 B0352LH3
D 6,0, T 6,0, L 45 B 151 B0354LH3
D 6, T 8, L 60 B 151 B0354LH6 Ø 6,0 mm
D 7, T 8, L 60 B 151 B0358LH6
D 8, T 8, L 60 B 151 B0362LH6
Cylinder
D 10, T 10, L 60 B 151 B0370LH6
D 12, T 10, L 60 B 151 B0374LH6
D 15, T 10, L 60 B 151 B0380LH6
