WORKSHOP EQUIPMENT - SURFACE FINISHING EQUIPMENT
HANDPIECES
ROTARY HANDPIECES EX231

30,000rpm / All-Arounder
Rated input voltage : 0-30V�DC
Max torque : 6�8 N�cm
Weight : 276 g
Standard collet size : 2�35 mm, 3�0 mm
Special collet size : 3�175 mm

REF Combination Max. Rotation Max. Torque Old REF
EX231 Motor EX23 + Head JA15 30,000 rpm 6�8 N�cm LA231

ROTARY HANDPIECES EX208

Swing stroke (0 - 1,6 mm) and stroke frequency (0 - 8�000 min-1) can be
adjusted freely�
Tool holding fixture to max� 4 mm�
Rated input volt�: 0-30 V =
Stroke frequency: 0 - 8�000 min-1
Motor torque: 0,073 Nm
Dimensions: Ø 31,6 x 166 x 53 mm
Weight: 0,290 kg

REF Combination Max. Rotation Max. Torque Old REF
EX208 Motor EX20 + Head JP11 8,000 rpm 9�8 N�cm LA208

ANGLE HAND PIECE 90° EX216

Hand operated quick release collet mechanism for rapid tool change�
Rated input volt�: 0-30 V =
Rotation speed: 0 - 15�000 min-1
Dimensions: Ø 31,6 x 166 x 53 mm
Weight: 0,200 kg

REF Combination Max. Rotation Max. Torque Old REF
EX216 Motor EX21 + Head JR21 15,000 rpm 8�8 N�cm LA216

ANGLE HAND PIECE 120° EX217

Hand operated quick release collet mechanism for rapid tool change�
Rated input volt�: 0-30 V =
Rotation speed: 0 - 15�000 min-1
Dimensions: Ø 31,6 x 166 x 53 mm
Weight: 0,200 kg

REF Combination Max. Rotation Max. Torque Old REF
EX217 Motor EX21 + Head JS21 15,000 rpm 8�8 N�cm LA217

CAD reference point
