DIAMOND FILES
PRECISION DIAMOND FILES Info

Diprofil Diamond Files are made from carefully selected diamonds, pre-
cisely bonded to obtain the best physical properties for added strength
and resistance to wear� Diamond files are excellent for use on carbide,
hardened steel, glass, ceramics and other similar materials�

Other shapes, dimensions and grit sizes available upon request�

GRITS SIZE CHART
STANDARDS STANDARDS
Surface Surface
finishing FEPA ASTM-E-11 finishing FEPA ASTM-E-11
Diamond Dimaond Diamond Dimaond
D251 60/70 D64 270/325
Rough D213 70/80 Fine D54 325/400
Grinding
D181 80/100 D46 500
D151 120/140 D30-40 600
Medium D126 140/170 D22-36 800
grinding D107 170/200 Ultra-fine D15-25 1000
D91 200/230 D10-20 1200
Fine D76 230/270 D8-16 15000

DIPROFIL , DIAMOND MACHINE FILES DLK ...
®

Features:
• Grainsize according to FEPA
• Diamond D151 (coarse)

REF D151 Dimensions Shape

DLK11D151 10 x 2,5 mm

STANDARD MACHINE FILES DLA...

15 mm
REF
Shape Size (mm)
Grit D64 Grit D151 Grit D181
Ø 3 mm 2x1 DLA2X1SD064 DLA2X1SD151 DLA2X1SD181
3x1 DLA3X1SD064 DLA3X1SD151 DLA3X1SD181
5
0 m
m
�
c
approx� 50 mm 4x1 DLA4X1SD064 DLA4X1SD151 DLA4X1SD181
a
4x2 DLA4X2SD064 DLA4X2SD151 DLA4X2SD181
5x2 DLA5X2SD064 DLA5X2SD151 DLA5X2SD181
Ø 1 DLA1D064 DLA1D151 DLA1D181
Ø 2 DLA2D064 DLA2D151 DLA2D181
Ø 3 DLA3D064 DLA3D151 DLA3D181
Ø 4 DLA4D064 DLA4D151 DLA4D181
R = 2,5x5 DLAR2-5R5D064 DLAR2-5R5D151 DLAR2-5R5D181
2x1 DLA2X1D064 DLA2X1D151 DLA2X1D181
3x1 DLA3X1D064 DLA3X1D151 DLA3x1D181
DLA4X1D151
DLA4X1D064
4x1
DLA4x1D181
CAD reference point 0,50x4 DLA5X2D064 DLA0-5X4D151 DLA5x2D181
DLA5X2D151
5x2
DLA1X4D151
1,00x4
DLAT2D064
DLAT2D181
DLAT2D151
2x2x2
3x3x3
DLAT4D151
DLAT4D181
4x4x4 DLAT3D064 DLAT3D151 DLAT3D181
DLAT4D064
