WORKSHOP EQUIPMENT - CONSUMABLES
CONSUMABLES
LUBRICANTS

SYNTHETIC LUBRICANT (SPRAY) / LUBRICATION PASTE C 138 / C 139

C 138 and C 139 are used when glide elements, apparatus and machinery
should not be contacted with mineral oil containing lubricants� Even under
wet , moist conditions oxidation free, high purified raw materials ensure a
permanent lubrication film�
The product is physiologically safe and without solid matter�
Temperature range: -30°C - +125°C

REF ml
C138EN 500
C139E 150

SPECIAL HIGH-EFFICIENCY OIL WITH MOS2 C 160

C 160 provides excellent emergency running pro-perties and is particularly
suitable for highly stressed axial guides with close tolerances, e�g� die sets
and similar equipment�
The addition of molybdenum reduces friction�

REF ml
C160E 400

MULTI-PURPOSE LUBRICANT (SPRAY) / LUBRICATION PASTE C 167 / C 168

C 167 and C 168 are heavy-duty lubricants wi-thout solid particles and with
high pressure enduring properties� The lubricating film does not tear even
under extreme conditions, thus the lubrication intervals are prolonged
considera bly� C 167 and C 168 is used for all moving parts in injection and
diecasting molds in the field of metal and plastics processing, eg� ejector pins,
coarse pitch axles, etc�
Temperature resistance to +180°C�

REF ml
C167EN 500
C168E 150

MOULDRELEASING AND LUBRICATING AGENT WITH TEFLON RZ 30

RZ 30 provides a waxlike release film being superior by its outstanding part-
ing effect and very good lubricating properties� By spraying a surface (e�g�
punching die) once or twice, it is possible to determine the guide clearance
of a punch guide to be made with casting resin RZ 20� The melting point of the
film is above 240°C� The sprayed-on mouldreleasing and lubricating agent is
insoluble in water and organic solvents� RZ 30 provides clean lubrication and CAD reference point
release without any contamination� TRI or C 120 grease solvent are used for
removing the release and lubricating film� Spray at room temperature�

REF ml
RZ30 400
