Page 139 - DME Workshop Equipment Catalogue 2023 EN
P. 139
SURF
CE FINISHING EQUIPMENT
A
WORKSHOP EQUIPMENT - SURFACE FINISHING EQUIPMENT
DIAMOND FILES
CONICAL HAND FILES DLL...
Total file length approx 140 mm� Shank diameter 3 mm�
REF
Shape Size (mm) Grit D30 Grit D46 Grit D76 Grit D107
1,7x2 DLL1D30 DLL1D46 DLL1D76 DLL1D107
1,7x4 DLL2D30 DLL2D46 DLL2D76 DLL2D107
1,7x6 DLL3D30 DLL3D46 DLL3D76 DLL3D107
ø3 DLL4D30
CONICAL HAND FILES SET DLL-Set
Set consisting of 10 different DLL-handfiles�
Types REF
DLL 1,2,3,4 in D30; DLL 1,2,3 in D46; DLL 1,2,3 in D76 DLLSET
DLL-4-D30; DLL 1,2,3 in D46; DLL 1,2,3 in D76; DLL 1,2,3 in DLLSETM
D107
CAD reference point
